Opened 14 years ago

Closed 14 years ago

#10001 closed Bug Report - General (fixed)

Corrupted bottom bar when playing 1080i HD-PVR content in OSX

Reported by: serversage@… Owned by: Nigel
Priority: minor Milestone: 0.25
Component: MythTV - Video Playback Version: 0.24.1
Severity: medium Keywords:
Cc: Ticket locked: no

Description

When playing back recordings on my MacMini (OSX 10.7 Lion) that were captured using an HD-PVR I get an 8 pixel high (based on a screen capture and a count of pixels) bar along the bottom of the screen that looks like corrupted video.

This is very similar to ticket #8409 I believe.

Attachments (3)

CorruptBarExample.jpg​ (194.6 KB ) - added by serversage@… 14 years ago.
Example screenshot
mythtv_playback.log​ (64.7 KB ) - added by serversage@… 14 years ago.
Output of mythfrontend -v playback
osx-quartz-1088.diff​ (476 bytes ) - added by markk 14 years ago.

Download all attachments as: .zip

Change History (10)

by serversage@…, 14 years ago

Attachment: CorruptBarExample.jpg​ added

Example screenshot

comment:1 by beirdo, 14 years ago

Status: new → infoneeded_new

Sounds like another place that needs a fix 1088->1080. What are you using for playback?

Technically, the HDPVR returns video that's 1920x1088 (to deal with the 16px alignment for the encoder), however, the bottom 8 rows are not at all initialized, so they are to be stripped off and not displayed. We've hit this in several other places as well, and it's possible we need one more tweak somewhere.

comment:2 by markk, 14 years ago

Milestone: unknown → 0.25

in reply to:  1 comment:3 by serversage@…, 14 years ago

I apologize for the long delay in replying. Playback is handled by the internal player, and has been tried on OSX 10.6 and OSX 10.7. I have not tried it on the backend which is running Ubuntu 11.04 with an NVidia card simply because my brain wasn't turned on.

To get around the problem I have set the cable box that feeds the HD-PVR to play only in 720p. Like an idiot, I deleted all the 1080i recordings so I no longer have anything on hand to test it with. But, if needed, I can easily get a few recordings if a patch comes along that needs to be run through it's paces.

comment:4 by markk, 14 years ago

Status: infoneeded_new → new

But what playback profile are you using for video? OpenGL or Quartz?

Please attach the output of mythfrontend -v playback

It doesn't matter if it is a 720p recording.

by serversage@…, 14 years ago

Attachment: mythtv_playback.log​ added

Output of mythfrontend -v playback

comment:5 by serversage@…, 14 years ago

Aah, sorry. Misunderstood. It is using Quartz, and the profile is currently set to CPU+. I dug out an old recording (I actually kept a 1080i), ran myth with -v playback, and then played a few seconds of video. The log is attached.

by markk, 14 years ago

Attachment: osx-quartz-1088.diff​ added

comment:6 by markk, 14 years ago

Owner: changed from markk to Nigel
Status: new → assigned

I've attached a patch (against master) that *should* fix the problem but I have no way of testing quartz output - so re-assigning to Nigel (though if anyone can confirm it works and doesn't break anything - please ping me).

comment:7 by Github, 14 years ago

Resolution: → fixed
Status: assigned → closed

Use GetVideoDispDim rather than GetVideoDim in OSX

Fixes #10001

This patch has been sitting for 3 months now. Let's put it in, and if there are issues, we'll rework it.

Signed-off-by: Gavin Hurlbut <ghurlbut@…>

Branch: master Changeset: 2175b3a00512a3db93e3e62bddd34bc1c62b6ed0
